IP67 200W Waterproof Power Supply, Non-Dimmable for Constant Outdoor Illumination 12V LED Driver
IP67 200W Waterproof Power Supply, Non-Dimmable for Constant Outdoor Illumination 12V LED Driver
Basic Properties
country of origin
Guangdong, China
brand name
KSPOWER
certificate
UL/cUL Class2 FCC CE GS ENEC ROHS etc.
product model
KS-200A-xx
Trading Properties
moq
2 pieces
unit price
The price is negotiable
payment method
T/T
supply capacity
300000pcs/monthly
Product Summary
IP67 200W Waterproof Power Supply, Non-Dimmable for Constant Outdoor Illumination 12V LED Driver Waterproof 200W LED Power Supply with Junction Box for Outdoor LED Strips Non-dimmable LED Driver. The KSPOWER - H series Non-dimmable LED driver is a constant voltage solution with single channel ...
Product Details
Highlight:
IP67 waterproof LED driver
,200W non-dimmable power supply
,12V outdoor LED driver
Warranty(Year):
5-Year
Lighting solutions service:
Lighting And Circuitry Design
Output Power:
40W / 60W / 80W /100W/120W/150W/180W/200W/240W/300W/320W
Output Type:
Single Phase
Input Voltage:
100-277V
Output Frequency:
50/60Hz
Application:
LED Strip Light,Pendants, Linears,Cove Lights
Material:
Aluminum Case
Warranty:
5 Years
Protection:
OCP, OVP, SCP, OTP
IP Rate:
IP65
Efficiency:
≥89%
Output:
12V24V36V48V
application:
Commercial Light Architectural Light Office Light Recessed Light Etc.
Product Description
IP67 200W Waterproof Power Supply, Non-Dimmable for Constant Outdoor Illumination 12V LED Driver
Waterproof 200W LED Power Supply with Junction Box for Outdoor LED Strips Non-dimmable LED Driver. The KSPOWER - H series Non-dimmable LED driver is a constant voltage solution with single channel operation. It accepts universal AC input voltage ranging from 100V to 277V, with optional output voltages of 12V, 24V, 36V, or 48V. Featuring high operating efficiency and PFC function, this Class P dimming power supply uses a low-profile metal aluminum case suitable for dry and damp environments, making it ideal for LED strips, signage, billboards, and landscape lighting.
Key Features
- Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use
- Single Channel & Constant Voltage mode
- Output Voltage: 12V/24V/36V/48V
- Driver Type: Class 2 Class P
- Enclosure: LISTED Enclosure with input and output wire
- Environmental: Dry and Damp
- Wiring Compartments with Knock-Outs for Clean and Easy Installation
- Current Limiting Overload Protection
- Flicker-Free Operation
- Smooth Ripple Free Output Voltage
- IP67 Rated Enclosure for Indoor and Outdoor Use
- 5-Year Warranty
- UL/cUL CE FCC RoHS ENEC GS Listed, SELV, Type HL
Technical Specifications
| Dimming Type | Series | Power | Model (xx=output voltage) | Output voltage | Output current | Input voltage | Size |
|---|---|---|---|---|---|---|---|
| Non-dimming | H | 40W | KS-40A-xx | 12V/24V/36V/48V | 3.3A | 1.67A | 1.11A | 0.83A | 100~277V 50/60Hz | 188*58*36mm |
| 60W | KS-60A-xx | 12V/24V/36V/48V | 5A | 2.5A | 1.67A | 1.25A | 188*58*36mm | |||
| 80W | KS-80A-xx | 12V/24V/36V/48V | 6.67A | 3.33A | 2.22A | 1.67A | 188*58*36mm | |||
| 96W | KS-96A-24 | 24V | / | 4A | / | / | 213*58*36mm | |||
| 100W | KS-100A-xx | 12V/24V/36V/48V | 8.33A | 4.16A | 2.78A | 2.08A | 188*58*36mm | |||
| 120W | KS-120A-xx | 12V/24V/36V/48V | 10A | 5A | 3.33A | 2.5A | 188*58*36mm | |||
| 150W | KS-150A-xx | 12V/24V/36V/48V | 12.5A | 6.25A | 4.16A | 3.13A | 188*58*36mm | |||
| 180W | KS-180A-12 | 12V/24V/36V/48V | 15A | / | / | / | 234*68*41mm | |||
| 200W | KS-200A-xx | 12V/24V/36V/48V | 16.66A | 8.33A | 5.55A | 4.16A | 188*58*36mm | |||
| 240W | KS-240A-xx | 12V/24V/36V/48V | 20A | 10A | 6.66A | 5A | 258*68*41mm | |||
| 300W | KS-300A-24 | 24V | / | 12.5A | / | / | 258*68*41mm | |||
| 320W | KS-320A-xx | 12V/24V/36V/48V | / | 13.33A | 8.88A | 6.66A | 258*68*41mm |
Note: Custom labeling, packaging, and cases are available. OEM and ODM services provided.
Why choose us?
Our IP67 H‑series constant‑voltage LED drivers deliver reliable power for indoor and outdoor lighting projects.
• Wide Universal Input: 100‑277V AC input fits residential, commercial and industrial applications, multiple output options 12V/24V/36V/48V available.
• IP67 Waterproof Housing: Aluminum low‑profile enclosure rated IP67, suitable for dry & damp locations, built‑in junction box with knock‑outs for fast, neat installation.
• Full Safety Certifications: UL/cUL, CE, FCC, RoHS, ENEC, GS, SELV, Type HL certified, compliant with Class 2 & Class P standards.
• Stable Performance: Flicker‑free, ripple‑free output, built‑in overload & current‑limiting protection with PFC function for high efficiency.
• Long‑term Reliability: Backed by 5‑year warranty, power range covers 40W‑320W to match different LED strip, signage, billboard and landscape lighting demands.
• Custom Service: Support OEM & ODM for custom labels, packaging and housings to meet your project requirements.
• Wide Universal Input: 100‑277V AC input fits residential, commercial and industrial applications, multiple output options 12V/24V/36V/48V available.
• IP67 Waterproof Housing: Aluminum low‑profile enclosure rated IP67, suitable for dry & damp locations, built‑in junction box with knock‑outs for fast, neat installation.
• Full Safety Certifications: UL/cUL, CE, FCC, RoHS, ENEC, GS, SELV, Type HL certified, compliant with Class 2 & Class P standards.
• Stable Performance: Flicker‑free, ripple‑free output, built‑in overload & current‑limiting protection with PFC function for high efficiency.
• Long‑term Reliability: Backed by 5‑year warranty, power range covers 40W‑320W to match different LED strip, signage, billboard and landscape lighting demands.
• Custom Service: Support OEM & ODM for custom labels, packaging and housings to meet your project requirements.
FQA
Q1. Can I have a sample order for adaptor ?
A: Yes, we welcome sample order to test and check quality.
Q2: Do you offer guarantee for the products?
A: Yes, all the power adapter come with 3-5 years warranty.
Q3. Do you have certificates for your products?
A: :Yes,we have UL/CUL,FCC,RoHS,CE,KC,SAA,TUV GS,PSE,KCC,NOM,S-Mark,BSMI Certifications.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline andsea shipping also optional.
Q5.What's your payment item?
A: Our standard payment is T/T in advance, Credit Card , E-Checking
Q6. Is it OK to print my logo on adaptor ?
A: Yes. Please inform us formally before our production and confirm the design firstly.
Q7: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.3%. Secondly, during the guarantee period, we will send new products with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
A: Yes, we welcome sample order to test and check quality.
Q2: Do you offer guarantee for the products?
A: Yes, all the power adapter come with 3-5 years warranty.
Q3. Do you have certificates for your products?
A: :Yes,we have UL/CUL,FCC,RoHS,CE,KC,SAA,TUV GS,PSE,KCC,NOM,S-Mark,BSMI Certifications.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline andsea shipping also optional.
Q5.What's your payment item?
A: Our standard payment is T/T in advance, Credit Card , E-Checking
Q6. Is it OK to print my logo on adaptor ?
A: Yes. Please inform us formally before our production and confirm the design firstly.
Q7: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.3%. Secondly, during the guarantee period, we will send new products with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
