60W 12V 5A Non Dimmable LED Driver with Metal Case and ETL CE Certification
Basic Properties
Trading Properties
Product Summary
Product Details
Security Camera Triac Dimmable Driver
,96W Triac Dimmable Driver
,Indoor Lighting Waterproof LED Driver
Product Description
The KSPOWER - E series Non-dimmable LED driver provides a constant voltage solution with single channel operation. It accepts AC input voltage range from 100V to 120V, delivering 12V output voltage with junction box. This switching LED power supply is compatible with single color or RGB light strips, string lights, wireless routers, ADSL Cat, HUB, switch, security cameras, speakers, receivers and audio/video power supplies.
| Input Voltage | 120Vac 60Hz & 230Vac 50Hz |
|---|---|
| Output Voltage | 12V/24V |
| Rated Current | 5A/2.5A |
| Rated Power | 60W |
| Efficiency | ≥ 90% |
| Working Temperature | -40℃ to +50℃ |
| Working Relative Humidity | 10%-100%Rh |
| Dimension (L*W*H) | 200*85*37mm / 7.88*3.35*1.46in |
| Certificate | ETL/cETL/Class2 |
- 100-120Vac 60Hz & 200-240Vac 50Hz Input
- 12V/24V PWM Output
- Single Channel & Constant Voltage mode
- Metal Iron Case with junction box
- ETL cETL Class2 CE Certified
- LISTED Enclosure with input and output wire
- Compatible with Forward & Reverse Phase, MLV, ELV
- High Power Factor (PF≥0.95)
- Full Dimming Range: 0-100%
- Flicker-Free operation
- Continuous, Smooth & Stable performance
- Protections: OCP, OVP, SCP, OTP
- For Dry Indoor Location
- 3 Years Warranty
Why choose us?
Triac & Phase-cut/Non-dimming,two modes optional
Indoor use led driver power supply
Metal iron shell,economical and durable
Input 100-120V,output 12V24VDC,20-96W
ETL/cETL Class2 certificate
| Package Type | Piece/Carton (pcs) | Piece Weight (KG) |
|---|---|---|
| OEM package | 50 | 0.26 |
| Dimension/Brown Box (mm) | Dimension/Carton (mm) | Gross Weight/Carton (KG) |
| 155*85*35 | 455*370*175 | 14 |
| Dimming Type | Series | Power | Model | Output Voltage | Output Current | Input Voltage | PF | Location | Size |
|---|---|---|---|---|---|---|---|---|---|
| Triac/Phase-cut | ET | 20W | ZH-EAC20W12-T | 12V | 1.7A | 100-120V 60Hz&200-240V 50Hz | ≥0.95 | Dry/Damp/Wet | 200*85*37mm |
| 20W | ZH-EAC20W24-T | 24V | 0.84A | 100-120V 60Hz&200-240V 50Hz | ≥0.95 | Dry/Damp/Wet | 200*85*37mm | ||
| 40W | ZH-EAC40W12-T | 12V | 3.34A | 100-120V 60Hz&200-240V 50Hz | ≥0.95 | Dry/Damp/Wet | 200*85*37mm | ||
| 40W | ZH-EAC40W24-T | 24V | 1.67A | 100-120V 60Hz&200-240V 50Hz | ≥0.95 | Dry/Damp/Wet | 200*85*37mm | ||
| 60W | ZH-EAC60W12-T | 12V | 5A | 100-120V 60Hz&200-240V 50Hz | ≥0.95 | Dry/Damp/Wet | 200*85*37mm | ||
| 60W | ZH-EAC60W24-T | 24V | 2.5A | 100-120V 60Hz&200-240V 50Hz | ≥0.95 | Dry/Damp/Wet | 200*85*37mm | ||
| 80W | ZH-EAC80W24-T | 24V | 3.33A | 100-120V 60Hz&200-240V 50Hz | ≥0.95 | Dry/Damp/Wet | 200*85*37mm | ||
| 96W | ZH-EA100W24-T | 24V | 4A | 100-120V 60Hz&200-240V 50Hz | ≥0.95 | Dry/Damp/Wet | 200*85*37mm |
