IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material

IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
Quality IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material factory
Quality IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material factory
Quality IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material factory
Quality IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material factory
Quality IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material factory
Quality IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material factory
Quality IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material factory

Basic Properties

country of origin
Guangdong, China
brand name
ZH
product model
ZF120A-2402000

Trading Properties

moq
100 pieces
unit price
$4.20-4.80/pieces

Product Summary

Products Description Model NO.ZF120A-2402000Input:100-240VAC 50/60HzOutput:24V DC 2A 48WOutput type:Single OutputMode:Constant VoltageSize:120*50*32mmWarranty:3 yearsProtection:OVP/OCP/SCPLeakage Current:0.5mA Max @230VAC InputRipple&Noise:

Product Details

Highlight:

IP20 rated LED power supply

,

48W LED driver with screw terminal

,

ABS PC LED transformer
Warranty(Year):
3-Year
Lighting solutions service:
Lighting And Circuitry Design
Output Power:
48W
Output Type:
Single Phase
Input Voltage:
100-240 VAC
Output Frequency:
47Hz~63Hz
Output Current:
2A
Efficiency:
80% Min
Working hours:
50000 Hrs
Size:
94*44*24mm
IP Rank:
IP20
Protections:
Short Circuit, Overload, Over Voltage, Over Temperature
Material:
ABS+PC
Warranty:
3 Years
Application:
LED Lighting, Celling Light Etc
Packing:
White Box + Carton
Product Name:
48W Led Driver 24V 2A

Product Description

Products Description
Model NO.
ZF120A-2402000
Input:
100-240VAC 50/60Hz
Output:
24V DC 2A 48W
Output type:
Single Output
Mode:
Constant Voltage
Size:
120*50*32mm
Warranty:
3 years
Protection:
OVP/OCP/SCP
Leakage Current:
0.5mA Max @230VAC Input
Ripple&Noise:
<120mV
Working temperature and humidity:
-10℃~+60℃, 20%~90%RH
Storage temperature and humidity:
-20℃~+85℃, 10%~85%RH
led light transformers 24w 26w 30w 36w 42w 48w 50w 58w 24v 2 a led driver 24 vdc 2a power supply with screw terminal output

The plastic case LED driver is constant voltage and IP20 design, universal AC input 100-240V, the dc 48W power supply is
compatible with LED lighting power supplies and open frame power supply. The LED transformer is RU cRU CE RoHS certified.
Contact Customers To Get Free Samples!
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
Company Profile
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
Working Room
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
Specification:
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
Nearly ¥3 Million Is Spent On Certification, Just To Make Customers Trust Our Quality
Exhibition
Hong Kong Exhibition in April 2024
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
IP20 Rated Single Power Supply Driver 48W LED Light Transformer with Screw Terminal Output and ABS PC Material
Product packaging
1.Sample is available.
2.Shipping method: available for express DHL/UPS/FedEx/TNT, Land, Ocean and others.
3. for 60W power adapter : each one put in one small inner brown box, then 50 pcs put in one standard carton.
Package
Piece/Carton(pcs)
Piece Weight(KG)
OEM package
50
0.26
Dimension/Brown Box(mm)
Dimension/Carton(mm)
Gross Weight/Carton(KG)
155*85*35
455*370*175
14
