100W Triac & ELV Dimmable LED Driver with 100-277VAC Input and 12V 24V 36V 48V Output for Universal Compatibility

100W Triac & ELV Dimmable LED Driver with 100-277VAC Input and 12V 24V 36V 48V Output for Universal Compatibility

Brand Name:	KSPOWER
Model Number:	KS-100LW-xxP
MOQ:	2 pieces
Price:	$29.65-38.45/pieces
Payment Terms:	T/T
Supply Ability:	300000pcs/monthly

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

UL cUL Class P CE ENEC Gs TYPE HL...

Application:

Lighting

Phase:

Single Phase

Coil Structure:

TOROIDAL

Coil Number:

AUTOTRANSFORMER

Input Voltage:

100V-277Vac

Product Name:

100 Watts Transformer Outdoor Ultra Slim LED Power Supply

Application:

Street Light, Tunnel Light, Wall Lamp,Spot Light

Warranty:

5 Years

Output Mode:

Pwm Output

Efficiency:

95%

Output:

12V 24V 36V 48V

Type:

Constant Voltage

Material:

Aluminum Case

IP Rate:

IP67

Packaging Details:

Brown box and Carton

Highlight:

Spot Light Outdoor LED Driver

UL Approved Outdoor LED Driver

277V·AC Triac Dimmable LED Driver

Product Description

Triac & ELV Dimmable 100W LED Driver

Universal Compatibility for Indoor Use

100-277 VAC 12V 24V 36V 48V Output IP67 Outdoor LED Driver 30-100W LED Transformer with dimmable / non-dimmable options.

Key Features

Universal AC input voltage 100-277VAC
High efficiency up to 91% with built-in active PFC function
Single channel & constant voltage mode with PWM style output
Comprehensive protection: OCP, OVP, SCP, OTP
Limited Power Source compliant
Certifications: cUL, RoHS, CE, ENEC, GS, Class P, SAA Approved

Function Options

Non-dimmable
Triac/Phase-cut Dimmable
4 in 1 dimmable (0-10V, 1-10V, PWM, resistance)
5 in 1 dimmable (0-10V, 1-10V, TRIAC, PWM, resistance)

Product Specifications

Typical lifetime > 50,000 hours
5 years warranty
Available with or without integrated Junction Box
IP65/IP67 Rated Enclosure for Indoor and Outdoor Use
Wiring compartments with knock-outs for clean and easy installation

Note: Custom label/package/case options available. OEM and ODM service provided.

Technical Specifications

Dimming Type	Series	Power	Model (xx=output voltage)	Output current (12V/24V/36V/48V)	Input voltage	Size
5 in 1 dimming	LP	30W	KS-30LW-xxP	2.5A / 1.25A / 0.83A / 0.62A	100~277V 50/60Hz	2703224.5mm
		40W	KS-40LW-xxP	3.33A / 1.66A / 1.11A / 0.83A		2703224.5mm
		60W	KS-60LW-xxP	5A / 2.5A / 1.67A / 1.25A		3103224.5mm
		80W	KS-80LW-xxP	6.66A / 3.33A / 2.22A / 1.66A		3103224.5mm
		100W	KS-100LW-xxP	8.33A / 4.16A / 2.78A / 2.08A		3553224.5mm
