Class 2 Rated 80W LED Driver with 5-Year Warranty and 100-277V Input for Residential Installations

Class 2 Rated 80W LED Driver with 5-Year Warranty and 100-277V Input for Residential Installations
Quality Class 2 Rated 80W LED Driver with 5-Year Warranty and 100-277V Input for Residential Installations factory
Quality Class 2 Rated 80W LED Driver with 5-Year Warranty and 100-277V Input for Residential Installations factory
Quality Class 2 Rated 80W LED Driver with 5-Year Warranty and 100-277V Input for Residential Installations factory
Quality Class 2 Rated 80W LED Driver with 5-Year Warranty and 100-277V Input for Residential Installations factory
Quality Class 2 Rated 80W LED Driver with 5-Year Warranty and 100-277V Input for Residential Installations factory
Quality Class 2 Rated 80W LED Driver with 5-Year Warranty and 100-277V Input for Residential Installations factory
Quality Class 2 Rated 80W LED Driver with 5-Year Warranty and 100-277V Input for Residential Installations factory
Quality Class 2 Rated 80W LED Driver with 5-Year Warranty and 100-277V Input for Residential Installations factory
Quality Class 2 Rated 80W LED Driver with 5-Year Warranty and 100-277V Input for Residential Installations factory

Basic Properties

country of origin
Guangdong, China
brand name
KSPOWER
certificate
UL 8750 Class2 Class P EN61347 GS ENEC
product model
KS-80LW-xxP

Trading Properties

moq
2 pieces
unit price
The price is negotiable
payment method
T/T
supply capacity
300000pcs/monthly

Product Summary

Class 2 Rated 80W LED Driver, Non-Dimmable, Safe for Residential Installations The KSPOWER LP series 5-in-1 dimmable LED driver provides a constant voltage solution with universal AC input voltage range from 100V to 277V. Available in 12V, 24V, 36V, or 48V output options, this driver offers high ...

Product Details

Highlight:

100W PWM Dimmable LED Driver

,

Safe PWM Dimmable LED Driver

,

Aluminum Case 0 10v pwm dimmer
Warranty(Year):
5-Year
Lighting solutions service:
Lighting And Circuitry Design
Output Power:
80W
Output Type:
PWM
Input Voltage:
100-277V
Output Frequency:
50/60Hz
Application:
LED Strip Light,Pendants, Linears,Cove Lights
Material:
Aluminum Case
Warranty:
5 Years
Protection:
OCP, OVP, SCP, OTP
IP Rate:
IP65
Efficiency:
≥90%
Power:
100W
Output:
12V

Product Description

Class 2 Rated 80W LED Driver, Non-Dimmable, Safe for Residential Installations
The KSPOWER LP series 5-in-1 dimmable LED driver provides a constant voltage solution with universal AC input voltage range from 100V to 277V. Available in 12V, 24V, 36V, or 48V output options, this driver offers high operating efficiency and PFC function. The low-profile aluminum enclosure is suitable for dry and damp locations, making it ideal for LED strips, signage, billboards, and landscape lighting applications.
Key Features:
  • Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use
  • Single Channel & Constant Voltage mode
  • Output Voltage: 12V/24V/36V/48V options
  • Driver Type: Class 2 Class P
  • LISTED Enclosure with input and output wiring
  • Multiple dimming options: Triac/Phase-cut, PWM, 0/1-10V or MLV/ELV Resistance Dimmable
  • Environmental rating: Dry and Damp locations
  • Wiring compartments with knock-outs for clean installation
  • Current limiting overload protection
  • Flicker-free operation with smooth ripple-free output
  • IP67 rated enclosure for indoor/outdoor use
  • 5-Year Warranty
  • UL/cUL CE FCC RoHS ENEC GS Listed, SELV, Type HL certified
Note: Custom labeling, packaging, and cases available. OEM and ODM services provided.
Dimming Connection Diagrams:
LED driver dimming connection diagram 1 LED driver dimming connection diagram 2
Technical Specifications:
Dimming Type Series Power Model (xx=output voltage) Output Current (12V) Output Current (24V) Output Current (36V) Output Current (48V) Input Voltage Size
5 in 1 dimming LP 30W KS-30LW-xxP 2.5A 1.25A 0.83A 0.62A 100~277V 50/60Hz 270*32*24.5mm
40W KS-40LW-xxP 3.33A 1.66A 1.11A 0.83A 270*32*24.5mm
60W KS-60LW-xxP 5A 2.5A 1.67A 1.25A 310*32*24.5mm
80W KS-80LW-xxP 6.66A 3.33A 2.22A 1.66A 310*32*24.5mm
96W KS-96LW-24P / 4A / / 355*32*24.5mm
100W KS-100LW-xxP 8.33A 4.16A 2.78A 2.08A 355*32*24.5mm
LED driver product image
FQA
.UL/cUL listed,5-years warranty
.IP65 waterproof,indoor & outdoor
100% burn-in tesed
.OEM/ODM:custom voltage,cable,label
Why choose us?
.Triac/0-10V/1-10V/ PWM/Resistance dimming/Non-dimming,multiple dimmable function combinations are available
.Suitable for forward & reverse phase dimming(MLV/ELV)
.Slim shape,suitable for tighter spaces
.Input voltage 100-277V,12V24V36V48V output voltage optional,and 30-100W power range
.Glue filling process,heat dissipation,waterproof and moisture-proof
.High efficiency and energy saving,high PFC,flicker-free
.Approved UL/cUL Class2 FCC CE GS ENEC RoHS cert
