| Brand Name: | KSPOWER |
| Model Number: | KS-60AW-12P |
| MOQ: | 50 pieces |
| Price: | $19.86-21.98/pieces |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 300000pcs/month |
| Package | Piece/Carton (pcs) | Piece Weight (KG) |
| OEM package | 50 | 0.26 |
| Dimension/Brown Box (mm) | Dimension/Carton (mm) | Gross Weight/Carton (KG) |
| 155*85*35 | 455*370*175 | 14 |
| Dimming Type | Series | Power | Model (xx=output voltage) |
Output voltage& Output current |
Input voltage | Size | |||
| 12V | 24V | 36V | 48V | ||||||
| Triac/Phase-cut | HTJ | 40W | KS-40AW-xxT | 3.3A | 1.67A | 1.11A | 0.83A | 100~277V 50/60Hz |
297*58*36mm |
| 60W | KS-60AW-xxT | 5A | 2.5A | 1.67A | 1.25A | ||||
| 80W | KS-80AW-xxT | 6.67A | 3.33A | 2.22A | 1.67A | ||||
| 96W | KS-96AW-24T | / | 4A | / | / | 322*58*36mm | |||
| 100W | KS-100AW-xxT | 8.33A | 4.16A | 2.78A | 2.08A | ||||
| 120W | KS-120AW-xxT | 10A | 5A | 3.33A | 2.5A | ||||
| 150W | KS-150AW-xxT | 12.5A | 6.25A | 4.16A | 3.13A | ||||
| 180W | KS-180AW-12T | 15A | / | / | / | 343*68*41mm | |||
| 200W | KS-200AW-xxT | 16.66A | 8.33A | 5.55A | 4.16A | ||||
| 240W | KS-240AW-xxT | 20A | 10A | 6.66A | 5A | 367*68*41mm | |||
| 300W | KS-300AW-24T | / | 12.5A | / | / | ||||
| 320W | KS-320AW-xxT | / | 13.33A | 8.88A | 6.66A | ||||
