Zf120a-1401000 3- Desktop Power Adapter 14V 10A DC Output for Soundbar 100% PC Desktop Version
Basic Properties
Trading Properties
Product Summary
Product Details
14V 10A desktop power adapter
,soundbar power adapter with warranty
,PC desktop power adapter 14V
Product Description
|
Input
|
100-240VAC, 50/60Hz
|
|
Ripple & Noise
|
≤120mV
|
|
Energy efficiency
|
Level VI
|
|
DC cord length
|
1.2m / 1.5m / 1.8m, etc.
|
|
DC jack size
|
5.5*2.1mm / 5.5*2.5mm / 3.5*1.35mm / 4.0*1.7mm / 2.5*0.7mm / 7.9*5.0mm / 4 pin
|
|
AC inlet
|
C6 / C8 / C14
|
|
AC cord length
|
1.2m / 1.5m / 1.8m, etc.
|
|
AC plug
|
US / EU / AU / UK / KR / CH / IT, etc.
|
|
Certifications
|
CLASS 2 UL1310 / cUL / UL / Level VI / CE / TUV / GS / FCC / KC / KCC / SAA / RoHS / CB / C-Tick / RCM / PSE / CCC
|
|
Protections
|
SCP / OPV / OCP / OTP / OPP
|
|
Working environment
|
-10°C~+40°C 5%~90%RH
|
|
Storage environment
|
-20°C~+85°C 5%~95%RH
|
|
Cooling method
|
Natural cooling down
|
|
RoHS compliant
|
Yes
|
|
Warranty
|
3 years
|
3. for 60W power adapter : each one put in one small inner brown box, then 50 pcs put in one standard carton.
|
Package
|
Piece/Carton(pcs)
|
Piece Weight(KG)
|
|
OEM package
|
50
|
0.26
|
|
Dimension/Brown Box(mm)
|
Dimension/Carton(mm)
|
Gross Weight/Carton(KG)
|
|
155*85*35
|
455*370*175
|
14
|
