Backlight 96w Triac Dimmable Driver High PFC 24V Dimmable Led Power Supply

Brand Name:	KSPOWER
Model Number:	KSE-80W24 / KSE-96W24
MOQ:	10 pieces
Price:	$27/pieces 10-499 pieces

Detail Information

Product Description

Detail Information

Place of Origin:

China (Mainland)

Warranty(Year):

5-Year

Lighting Solutions Service:

Lighting And Circuitry Design

Output Power:

80W/96W

Output Type:

Single Phase

Input Voltage:

100V-120Vac & 200-240Vac

Output Frequency:

50/60Hz

Output Current:

3.33A / 4.0A

Product Name:

Continuous Smooth Led Transformer 24v80w Dc Led Driver

Output Voltage:

24V

Efficiency:

>90%

Protections:

OCP, OVP, SCP, OTP

Warranty:

3 Years

Certification:

ETL CETL CE ROHS UL Class2

Dimension:

200*85*37mm (L*W*H)

Material:

Iron Case

Color:

Silver, Black, White, Blue, Gray Or Custom.

Dimming Mode:

Traic /Phase-Cut Dimmable

Highlight:

96w Triac Dimmable Driver

Backlight Triac Dimmable Driver

High PFC Dimmable Led Power Supply

Product Description

Products Description

Features:
* 100-120Vac 60Hz & 200-240Vac 50Hz Input
* 12V/ 24V PWM Output
* Single Channel & Constant Voltage mode
* Enclosure With Junction Box
* ETL cETL Class2 CE Cert
* Enclosure: LISTED Enclosure with input and output wire
* For Forward & Reverse Phase, MLV, ELV
* High Power Factor, PF≥0.95
* Full Dimming Range:0-100%
* Flicker-Free
* Continuous & Smooth & Stable
* Protections: OCP, OVP, SCP, OTP
*For Dry Indoor Location
* 3 Years Warranty

Note:Any custom label/package/case is acceptable, provide OEM and ODM service

Specification:

Model No.	Output Power	Output Voltage	Output Current	Efficiency	Dimension
KSE-24W	20W	12V/24V	1.7A/0.84A	≥88%	(7.93.341.45)inch 2008537MM
KSE-40W	40W	12V/24V	3.34A/1.67A	≥88%
KSE-60W	60W	12V/24V	5A/2.5A	≥88%
KSE-80W	80W	24V	3.33A	≥88%
KSE-96W	96W	24V	4.0A	≥88%
